Specifications

• Takeoff Weight: Approx. 1,063 g; Maximum 1,263.5 g (including propeller guards and accessories)
• Dimensions:
  • Folded (with propellers): 257.6 × 124.8 × 106.6 mm
  • Unfolded (without propellers): 328.7 × 390.5 × 135.2 mm

Flight Performance

• Maximum Speed:
  • Horizontal: 25 m/s (Sport Mode, windless); 27 m/s (with tailwind)
  • Ascent/Descent: 10 m/s (Sport Mode)
• Flight Time:
  • Maximum Flight Duration: 51 minutes (windless, photo mode)
  • Maximum Hover Time: 45 minutes
• Maximum Flight Range: 41 km
• Wind Resistance: 12 m/s (approximately Level 5 wind)
• Maximum Takeoff Altitude: 6,000 m
• Operating Temperature: -10 ℃ to 40 ℃
• Positioning System: GPS + Galileo + BeiDou
• Onboard Storage: 64 GB (Standard Version); 512 GB (Creator Version)

Triple-Camera Imaging System

1. Main Camera
   • Aperture: f/2.8
   • Field of View: 35°
   • Video: 4K/60 fps, up to 120 fps slow motion
2. Telephoto Camera (168 mm equivalent)
   • Image Sensor: 1/1.5-inch CMOS, 50 million effective pixels
   • Aperture: f/2.8
   • Field of View: 15°
   • Video: 4K/60 fps, up to 100 fps slow motion

General Imaging Specifications

• File Formats: JPEG / DNG (RAW); MP4 (H.264 / H.265)
• Bitrate: Up to 180 Mbps (H.265); Up to 1,200 Mbps (H.264 ALL-I, 512 GB version only)
• Digital Zoom: Main camera: 1×–2.5×; Mid-range telephoto: 2.5×–6×; Telephoto: 6×–24×

Gimbal

• Type: 3-axis mechanical gimbal
• Controllable Range:
  • Tilt: -90° to 70° (supports 70° upward shooting)
  • Roll: -40° to 400° (360° continuous rotation)
• Angular Vibration: ±0.001° (during hovering)

Obstacle Sensing & Avoidance

• System: Omnidirectional dual vision sensors + forward LiDAR + downward infrared sensors
• Detection Range: Front/Rear/Sides: 0.5–24 m; Top/Bottom: 0.5–18 m
• Low-Light Performance: Obstacle detection down to 0.1 lux (aided by LiDAR)
• Effective Avoidance Speed: Horizontal: ≤18 m/s; Vertical: ≤6 m/s

Video Transmission (O4+)

• Maximum Transmission Range: 30 km (FCC standard, unobstructed line of sight)
• Image Quality: 1080p/60 fps, 10-bit HDR
• Frequency Bands: 2.4 GHz / 5.2 GHz / 5.8 GHz
• Latency: Approx. 130 ms (when paired with DJI RC 2 / RC Pro 2)
• Wi-Fi Download Speed: Wi‑Fi 6, up to 800 MB/s

Battery & Charging

• Battery: 6,654 mAh, 95.3 Wh
• Voltage: 14.32 V (4-cell lithium-ion battery)
• Charging:
  • With 240 W charger: 1 battery fully charged in 51 minutes; 3 batteries charged simultaneously in 90 minutes
  • Onboard charging (65 W): Approx. 115 minutes for full charge

Remote Controller (DJI RC 2 / RC Pro 2)

• Display: 7-inch high-brightness screen (RC Pro 2 features mini-LED); supports one-touch portrait mode via screen rotation
• Features: 6 antennas, built-in O4+ transmission system; maximum control range of 30 km

Key Highlights

• Versatile Triple-Camera Setup: 100MP main camera plus dual telephoto lenses; supports 4K/60 fps video and 10-bit color across all focal lengths.
• Extended Flight Time: Up to 51 minutes flight duration; maximum speed of 90 km/h.
• Full-Range Gimbal: 360° endless roll rotation + 70° upward tilt capability.
• High-Performance Obstacle Avoidance: Omnidirectional sensing effective down to 0.1 lux for safer night flights.
• Long-Range Transmission & High-Speed Connectivity: O4+ system with 30 km range; Wi‑Fi 6 for fast file downloads.
