Y50-X8 Octocopter UAV Basic Specification (English Version)
I. Airframe Structural Parameters
| Item |
Specification |
| Configuration |
X8 coaxial octocopter layout (8 motors & 8 propellers) |
| Diagonal Wheelbase |
1925mm |
| Overall Deployed Dimension |
1465×1475×595mm |
| Folded Storage Dimension |
770×985×700mm (for vehicle transportation) |
| Airframe Material |
Full carbon-fiber arms + aviation aluminum fuselage with anti-corrosion waterproof coating, IP54 splash-proof for waterborne operations |
| Empty Weight (with standard 18S battery) |
48kg |
| Max. Payload Capacity |
50kg (rated standard payload) |
| Max Takeoff Weight (fully loaded with 50kg payload) |
98kg |
| Propeller Spec |
41-inch foldable high-efficiency carbon-fiber propellers |
II. Power & Endurance (Standard Single 18S Battery Configuration)
- Battery: 18S 30000mAh high-voltage industrial lithium battery
- Hover Endurance (No Payload): 20.5 mins
- Hover Endurance (Full 50kg Payload): 11～13 mins
- Optional Dual-battery Upgrade: Extended full-load endurance up to 17 mins (extra cost applicable)
- Power System: X11 high-power brushless power package
III. Flight Controller, Positioning & Video Transmission (Government & Enterprise Standard Configuration)
- Positioning: Beidou+GPS dual-system with dual-antenna RTK centimeter-level positioning; horizontal accuracy ±1cm, vertical accuracy ±2cm for fixed-point hovering (ideal for ship-borne water rescue missions)
- RC & Data Transmission Range: 10km effective control radius
- Industrial HD Video Transmission: 15km long-distance digital HD transmission, equipped with nose and downward-facing dual HD cameras
- Obstacle Avoidance: Front & rear dual-side radar obstacle avoidance
- Flight Modes: Manual control, A-B autonomous flight, pre-programmed route cruise, one-key return-to-home, low-voltage forced landing
- Accessories: Original industrial remote controller, Android ground station APP, real-time flight data monitoring backend
IV. Flight Environmental Performance (Flood & Water Emergency Standard Index)
- Max Level Flight Speed: 20m/s (72km/h)
- Rated Wind Resistance: Level 6 wind (≤13.8m/s), stable hovering under rain and choppy water conditions
- Max Operating Altitude: 500m (regular working height: 30~50m for water rescue)
- Operating Temperature: -20℃～+55℃, built-in battery thermal insulation for low-temperature water scenarios
V. Standard Bare-aircraft Package List
- X8 carbon-fiber airframe + full octocopter power assembly
- RTK flight control system + front/rear obstacle avoidance module
- 1×18S 30000mAh original lithium battery + high-power matching charger
- Complete set of 15km RC data link & HD video transmission system
- Original tool kit & storage accessories
VI. Common Optional Upgrades for Lighting Application
- 3000W waterborne LED lighting pod + high-altitude loudspeaker module
- Automatic life ring dropping module
- 150m tethered power supply kit (24-hour persistent hovering capability)
- Hybrid gasoline-electric power upgrade
VII. Optional Configuration & Quotation
-
3000W high-power lighting system: 200,000 lumens, covering 20,000 ㎡ of water surface, IP56 salt-spray proof, remotely adjustable lamp pitch angle
Full set landing price: USD 48,680
-
Complete package (aircraft + full lighting set +150m photoelectric composite tether cable + auto-retracting ground power station, compatible with mains & diesel dual power supply)
Total package price: USD 68,960
