ABC Dry Powder Firefighting Quadcopter (4-Axis 8-Rotor, High-Rise Window-Breaking + ABC Ultra-Fine Dry Powder Spraying, 60kg Payload)
Full Aircraft Flight Specifications
Configuration: 4-axis 8-coaxial rotor, airframe of carbon fiber + aerospace aluminum alloy
Wheelbase: 1850mm; deployed dimension: 1850×1850×800mm; folded dimension: 650×650×800mm
Empty weight (including batteries): 50kg; Maximum Takeoff Weight (MTOW): 120kg; Rated dry powder payload: 60kg
Endurance: 30～40 mins at no load; 12～15 mins with full 60kg dry powder load
Battery: 12S4 series lithium battery, 46000mAh
Service Ceiling & Flight Speed: practical ceiling 1200m, level flight speed 0～16m/s; operating height 0～300m for high-rise building missions
Wind resistance: up to Grade 5 wind (8m/s); hover accuracy: horizontal ±0.5m, vertical ±0.5m
Remote control range: 3～5km in open terrain, HD video downlink for real-time fire scene transmission
Safety features: GPS + attitude dual altitude hold, low-voltage alarm, one-click auto return-to-home upon loss of control
ABC Ultra-Fine Dry Powder Fire Suppression System Specs
Dry powder tank capacity: 60kg ABC ultra-fine dry powder extinguishing agent
Discharge modes: pressurized high-pressure spraying + window-breaking fire bomb dual operation
Powder spraying range: 6.5～8m, continuous spraying duration 8～12s, single operation covers 35～50㎡ fire area
Window-breaking bomb: single bomb ≤3kg with aluminum alloy casing; long-range launch breaks window followed by in-room powder injection
Application scenarios: initial fires in high-rise apartments, office buildings, power distribution rooms and oil facilities
II. Walkera WK1900 60kg Dry Powder Firefighting Drone (4-Axis 8-Rotor, Long-Range Video Transmission)
Flight Parameters
Max dry powder payload: 60kg; no-load flight endurance: 43 mins
RC & video transmission range: 12km; equipped with LiDAR omnidirectional obstacle avoidance, IP43 ingress protection rating
Modular foldable airframe; matched with 5.5-inch high-brightness ground controller display and onboard fire control aiming system
Wind resistance: Grade 6 wind; supports fully autonomous route planning and fixed-point precise powder dispersion
Dry Powder Operation Performance
Full load of 60kg ultra-fine dry powder with total fire suppression coverage of approx. 184m³; fixed-point injection and zoned flooding fire suppression.
III. General Industrial Standard Specification (T/CFPA009-2022 Pressurized Dry Powder Device for Firefighting Drones)
Extinguishing agent: ABC ultra-fine dry powder (particle size ≤20μm)
Working pressure of pressurized tank: 1.2～1.6MPa
60kg full-load model: full tank discharge duration 10±2s, capable of putting out initial fires in 3～5 separate high-rise compartments per sortie
Operating environment: -20℃～+55℃, short-term operation permitted in light rain (IP43/IP54 protection)
