DYM1000M – Technical Specifications
-
-
Cell Chemistry: LFP (Lithium Iron Phosphate)
-
Energy Capacity: 1008 Wh (typical value)
-
Cycle Life: Retains over 80% of rated capacity after 4,000 full charge-discharge cycles.
A full cycle refers to one complete charge and discharge cycle. Tested in a laboratory environment at 25 °C: charged in standard mode for DJI Power 1000 Mini and discharged at an output power of 400 W.
-
Net Weight: Approx. 11.5 kg
-
Dimensions: 314 mm (L) × 212 mm (W) × 216 mm (H)
Port Configuration
- AC Output Ports × 2 (China / EU / Australia / UK standard sockets)
- AC Output Ports × 4 (US / Japan standard sockets)
- USB-C Port × 1
- Retractable USB-C Cable × 1
- USB-A Ports × 2
- SDC Port × 1
- AC Input Port × 1
Regions adopting US and Japanese socket standards are equipped with 4 AC outlets. Other regions feature 2 AC outlets due to different socket dimensions.
- Maximum Operating Altitude: 5000 m
Output Specifications
AC Output
Low-Version
- 100–120 V AC, 50/60 Hz; Max current 10 A, Peak 1000 W, Continuous 800 W
- 100–120 V AC; Max current 14.4 A, Peak 1440 W (Bypass Mode)
High-Version
- 220–240 V AC, 50/60 Hz; Max current 4.5 A, Peak 1000 W, Continuous 800 W
- 220–240 V AC; Max current 10 A, Peak 2200 W (Bypass Mode)
AC output parameters vary by country and region.
USB-A Output
- 5 V, 2.4 A
- Maximum output per port: 12 W
USB-C Output
- 5 V / 5 A
- 9 V / 5 A
- 12 V / 5 A
- 15 V / 5 A
- 20 V / 5 A
- Maximum output per port: 100 W
The USB-C port supports up to 100 W output. When both the retractable USB-C cable and the USB-C port power devices simultaneously, the total combined power is 150 W: up to 100 W from the retractable cable and up to 50 W from the standalone USB-C port.
SDC Output
Input Specifications
AC Input
Low-Version
- 100–120 V AC, 50/60 Hz; Max current 10 A, Peak 1000 W, Continuous 800 W
- 100–120 V AC; Max current 14.4 A, Peak 1440 W (Bypass Mode)
High-Version
- 220–240 V AC, 50/60 Hz; Max current 4.5 A, Peak 1000 W, Continuous 800 W
- 220–240 V AC; Max current 10 A, Peak 2200 W (Bypass Mode)
AC input parameters vary by country and region.
USB-C Input
- Maximum charging power: 100 W
SDC Input
Operating Temperature
- Discharge Temperature Range: −10 °C ~ 45 °C
- Charging Temperature Range: −10 °C ~ 45 °C
- Storage Temperature Range: −10 °C ~ 45 °C
Wi-Fi & Bluetooth
Operating Frequency Bands & EIRP
-
- Frequency: 2.4000–2.4835 GHz
- EIRP: < 20 dBm (CE/SRRC/MIC compliant)
-
- Frequency: 2.4000–2.4835 GHz
- EIRP: < 7 dBm
